| Producent |
GIGABYTE |
| Maksymalna wielkość pamięci |
256 GB |
| Chipset płyty głównej |
AMD B850 |
| Wymiary [S x W] (mm) |
305 x 244 |
| Opakowanie |
BOX |
| Gniazdo procesora |
Socket AM5 |
| Standard pamięci |
DDR5-8200 (OC), DDR5-8000 (OC), DDR5-7800 (OC), DDR5-7600 (OC), DDR5-7200 (OC), DDR5-7000 (OC), DDR5-6800 (OC), DDR5-6666 (OC), DDR5-6600 (OC), DDR5-6400 (OC), DDR5-6200 (OC), DDR5-6000 (OC), DDR5-5600 (OC), DDR5-5200, DDR5-4800, DDR5-4400 |
| Format płyty |
ATX |
| Wbudowana karta graficzna |
Brak lub AMD Radeon™ Graphics (zależy od procesora) |
| Obsługiwane typy procesorów |
AMD Ryzen™ |
| Uwagi do procesora |
AMD Socket AM5, support for:, AMD Ryzen™ 9000 Series Processors/, AMD Ryzen™ 8000 Series Processors/, AMD Ryzen™ 7000 Series Processors |
| BIOS |
256 Mbit flash AMI UEFI; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Tryb pracy pamięci RAM |
Dual Channel |
| Gniazda karty graficznej |
DisplayPort, HDMI |
| Uwagi do karty graficznej |
Integrated Graphics Processor with AMD Radeon™ Graphics support:, - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 1.4 version and HDR., - 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz, Support for HDMI 1.4 version |
| Zintegrowana karta dźwiękowa |
Realtek ALC1220 7.1 Surround Sound High Definition Audio CODEC |
| Gniazda karty dźwiękowej |
2x Audio Jack, Wyjście optyczne S/PDIF , Wewnętrzne gniazdo audio przedniego panelu |
| Złącza PCI Express x16 |
3 |
| Uwagi do złącz PCI |
CPU:, 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, The PCIEX16 slot can only support a graphics card or an NVMe SSD, Chipset:, - 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 |
| Port Bluetooth |
Bluetooth V5.4 |
| Port równoległy (LPT) |
Brak |
| Inne porty i gniazda |
CPU fan header, CPU fan/water cooling pump header, 3x system fan headers, System fan/water cooling pump header, RGB LED strip header, Gniazdo modułu TPM, Reset button, Reset jumper, Clear CMOS jumper, Power-on button(s), Q-Flash Plus button, 2x SMA antenna connectors (2T2R) |
| Gniazdo zasilania |
ATX (24-pin) + ATX12V (8-pin) + ATX12V (4-pin) |
| Uwagi do pamięci RAM |
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and , Extreme Memory Profile (XMP) memory modules |
| Okres rękojmi w miesiącach |
36 |
| Zintegrowany kontroler SATA |
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 3x M.2 - RAID 0,1,5,10 |
| Uwagi do kontrolera SATA |
1x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, , M key, type 25110/22110/2580/2280 SSDs:, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, , M key, type 25110/22110/2580/2280 SSDs:, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs, 1 x M.2 connector (M2D_SB), integrated in the Chipset, supporting Socket 3,, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSDs, RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices, RAID 0, RAID 1, and RAID 10 support for SATA storage devices, RAID 5 is only available on AMD Ryzen™ 9000 Series Processors |
| Port Wi-Fi |
IEEE 802.11a/b/g/n/ac/ax/be |
| Port LAN |
1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®) |
| Port PS/2 |
Brak |
| Port szeregowy (COM) |
Brak |
| Maksymalna ilość portów USB 2.0 |
8 |
| Maksymalna ilość portów USB 3.x |
11 |
| Porty USB na panelu tylnym |
4x USB 2.0 + 5x USB 3.0 + 2x USB 3.1 + 1x USB 3.1 Type-C |
| Gniazda USB na płycie głównej |
2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.2 Type-C (1 port) |
| Cechy |
B850 A ELITE WF7 ICE |
| Baza SCIP |
Nie |
| Ilość złącz pamięci DDR5 |
4 |
| Uwagi do WiFi / BT |
Support for 11be 160MHz wireless standard(Actual data rate may vary , depending on environment and equipment., Wi-Fi 7 features require Windows 11 SV3 to function properly (There is no , support driver for Windows 10), Wi-Fi 7 channels on 6GHz band availability depends on individual country's , regulations |
