| Producent |
ASUS |
| Wyposażenie dodatkowe |
2 x SATA 6Gb/s cables, 1 x ASUS WiFi Q-Antenna, 1 x M.2 Rubber Package, 2 x Screw Packages for M.2 SSD, 1 x Quick start guide |
| Maksymalna wielkość pamięci |
192 GB |
| Chipset płyty głównej |
AMD X870 |
| Wymiary [S x W] (mm) |
305 x 244 |
| Gniazdo procesora |
Socket AM5 |
| Format płyty |
ATX |
| Wbudowana karta graficzna |
Brak lub AMD Radeon™ Graphics (zależy od procesora) |
| Obsługiwane typy procesorów |
AMD Ryzen™ (AM5) |
| Uwagi do procesora |
AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors, Refer to https://www.asus.com/support/download-center/ for CPU support list |
| BIOS |
256 Mb Flash ROM, UEFI AMI BIOS |
| Tryb pracy pamięci RAM |
Dual Channel |
| Gniazda karty graficznej |
HDMI, 2x USB4 Type-C |
| Uwagi do karty graficznej |
Graphics specifications may vary between CPU types. Please refer to , AMD CPU specifications, Supports 4K@60Hz as specified in HDMI 2.1, Supports max. 4K@60Hz as specified in DisplayPort 1.4a |
| Zintegrowana karta dźwiękowa |
Realtek ® 7.1 Surround Sound High Definition Audio CODEC |
| Gniazda karty dźwiękowej |
3x Audio Jack, Wewnętrzne gniazdo audio przedniego panelu, Wewnętrzne gniazdo S/PDIF Out |
| Złącza PCI Express x16 |
4 |
| Uwagi do złącz PCI |
AMD Ryzen™ 9000 & 7000 Series Desktop Processors:, - 1 x PCIe 5.0 x16 slot (supports x16 mode), AMD Ryzen™ 8000 Series Desktop Processors:, - 1 x PCIe 4.0 x16 slot (supports x8/x4 mode), AMD X870 Chipset:, - 3 x PCIe 4.0 x16 slots (support x1 mode), Please check the PCIe bifurcation table on the support site, Specifications vary by CPU types, PCIEX16(G4)_1 shares bandwidth with M.2_2. PCIEX16(G4)_1 will be disabl, disabled when M.2_2 runs, PCIEX16(G4)_2 and PCIEX16(G4)_3 share bandwidth with , M.2_3. PCIEX16(G4)_2 and PCIEX16(G4)_3 will be disabled when M.2_3 runs |
| Uwagi do karty sieciowej |
ASUS LANGuard |
| Port Bluetooth |
Bluetooth V5.4 |
| Port równoległy (LPT) |
Brak |
| Inne porty i gniazda |
4-pin CPU Fan header, 4-pin CPU OPT Fan header, 4-pin AIO Pump header, 4x 4-pin Chassis Fan headers, 3x Addressable RGB Gen2 LED connector, Clear CMOS header, SPI TPM header (14-1pin), 10-1 pin System Panel header |
| Gniazdo zasilania |
ATX (24-pin) + 2x ATX12V (8-pin) |
| Uwagi do pamięci RAM |
Supports up to 8000+MT/s(OC) with Ryzen™ 9000 & 8000 & 7000 Series Processo, ECC and Non-ECC, Un-buffered DIMM*, Supports AMD Extended Profiles for Overclocking (EXPO™), ASUS Enhanced Memory Profile (AEMP), Supported memory types, data rate (speed), and number of DRAM modules vary , depending on the CPU and memory configuration, for more information please, refer to CPU/Memory Support list under the Support tab of product , information site or visit https://www.asus.com/support/download-center/, Non-ECC, un-buffered DDR5 memory supports On-Die ECC function |
| Uwagi do karty dźwiękowej |
Jack-detection, Multi-streaming, Front Panel Jack-retasking, Supports up to 24-Bit/192 kHz playback", A chassis with an HD audio module in the front panel is required to, support 7.1 Surround Sound audio output |
| Okres rękojmi w miesiącach |
36 |
| Zintegrowany kontroler SATA |
Chipset+CPU: 2x SATA III 6Gb/s + 4x M.2 |
| Uwagi do kontrolera SATA |
AMD Ryzen™ 9000 & 7000 Series Desktop Processors:, - M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode), AMD Ryzen™ 8000 Series Desktop Processors:, - M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode), AMD X870 Chipset:, - M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), - M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode), - M.2_4 slot (Key M), type 2280 (supports PCIe 3.0 x2 mode), AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and , SATA RAID 0/1. RAID 5 Function is only supported by AMD Ryzen™ 9000 series, PCIEX16(G4)_1 shares bandwidth with M.2_2. PCIEX16(G4)_1 will be disabled , when M.2_2 runs, PCIEX16(G4)_2 and PCIEX16(G4)_3 share bandwidth with M.2_3. PCIEX16(G4)_2 , and PCIEX16(G4)_3 will be disabled when M.2_3 runs, M.2_4 shares bandwidth with SATA6G_1 and SATA6G_2. M.2_4 will be disabled , when SATA6G_1 or SATA6G_2 runs. |
| Port Wi-Fi |
IEEE 802.11a/b/g/n/ac/ax/be |
| Port LAN |
1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®) |
| Port PS/2 |
Port combo klawiatury/myszy PS/2 |
| Port szeregowy (COM) |
1x wewnętrzne gniazdo portu COM |
| Maksymalna ilość portów USB 2.0 |
6 |
| Maksymalna ilość portów USB 3.x |
7 |
| Porty USB na panelu tylnym |
4x USB 2.0 + 3x USB 3.1 + 1x USB 3.1 + 2x USB4 Type-C |
| Gniazda USB na płycie głównej |
2x USB 2.0 (2 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.1 Type-C (1 port) |
| Cechy |
X870-P WIFI;ATX |
| Maksymalna ilość portów USB 4.0 |
2 |
| Baza SCIP |
Nie |
| Ilość złącz pamięci DDR5 |
4 |
| Uwagi do WiFi / BT |
2x2 Wi-Fi 7 (802.11be), Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate, Wi-Fi features may vary depending on the operating system, For Windows 11, Wi-Fi 7 will require 24H2 or later version for full , functions, Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E, For Windows 10, please note that no driver is available , please refer to , the Wi-Fi chipset vendor's website for details, The Bluetooth version may vary, please refer to the Wi-Fi module , manufacturer's website for the latest specifications |
